ANSI /ASME B16.47 Series A Flange( MSS SP44)
ASME B16.47 SER.A Weld Neck Flange Class 600
Standard: ASME B16.47 SER.A
Flange type: Weld Neck Flange
Size range: 12
Pressure: Class 600
Material: Stainless steel,Alloy Steel,Carbon Steel,Copper&Nickel Alloy,Nickel Alloy,etc.
▲Standard: ASME B16.47 SER.A
▲Flange type: Weld Neck Flange
▲Size range: 12"-60"
▲Pressure : Class 600
▲Material:
1) Stainless Steel Material:
ASTM A182 F304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H,904L
Duplex stainless steel UNS S32304,S31803,S32205.
Super Duplex stainless steel UNS S32750/S32760/S31254/S31260/S32550/S32707
2) Carbon Steel Material:
ASTM A105, A350 LF2,P235GH,P250GH,SS400,Q235,C22.8,20#,16mn.
3) Alloy Steel Material:
ASTM A 182, GR F1,F5, F9, F11, F22, F91
ASTM A694 F42/F46/F52/F60/F65/F70/F80.
4) Copper&Nickel Alloy Material:
CU/NI 90/10, CU/NI 70/30
5) Nickel Alloy Material:
Monel 400 & 500, Inconel 600 & 625, Incolloy 800, 825, Hastelloy C22,C276
▲Surface treatment: Anti-rust oil, transparent/yellow/black,Anti-rust paint, Zinc, Hot dipped/ Electric galvanized.
▲Usage: Oil field, Offshore, Water system, Shipbuilding, Natural gas,Electric power, Pipe projects,etc.
ASME B16.47 SER.A Weld Neck Flange Class 600 Dimensions in mm.
|
Pipe Normal Diam. |
O.D.of Flange |
Thickness |
Length Through Hub |
Diam. at Base of Hub |
Bore |
Diam. of Hub at Bevel |
Raised Face Diam. |
Fillet Radius Min. |
Diam. of Bolt Circle |
No. of Bolt Holes |
Diam. of Bolt Holes |
Diam. of Bolt |
Approx. Weight (KG) |
|
|
Wall Thickness |
||||||||||||||
|
9.5mm |
12.7mm |
|||||||||||||
|
O |
C |
Y |
X |
B |
A |
R |
r |
|||||||
|
26" |
1016.0 |
108.0 |
222.3 |
747.8 |
641.4 |
635.0 |
660.4 |
749.3 |
12.7 |
914.4 |
28 |
50.8 |
1 7/8 |
426.4 |
|
28" |
1073.2 |
111.3 |
235.0 |
803.1 |
692.2 |
685.8 |
711.2 |
800.1 |
12.7 |
965.2 |
28 |
53.8 |
2 |
480.8 |
|
30" |
1130.3 |
114.3 |
247.7 |
862.1 |
743.0 |
736.6 |
762.0 |
857.3 |
12.7 |
1022.4 |
28 |
53.8 |
2 |
548.9 |
|
32" |
1193.8 |
117.3 |
260.4 |
917.4 |
793.8 |
787.4 |
812.8 |
914.4 |
12.7 |
1079.5 |
28 |
60.5 |
2 1/4 |
623.7 |
|
34" |
1244.6 |
120.7 |
269.7 |
973.1 |
844.6 |
838.2 |
863.6 |
965.2 |
14.2 |
1130.3 |
28 |
60.5 |
2 1/4 |
698.5 |
|
36" |
1314.5 |
124.0 |
282.4 |
1031.7 |
895.4 |
889.0 |
914.4 |
1022.4 |
14.2 |
1193.8 |
28 |
66.5 |
2 1/4 |
773.4 |
|
38" |
1270.8 |
152.4 |
254.0 |
1022.4 |
946.2 |
939.8 |
965.2 |
1054.1 |
14.2 |
1162.1 |
28 |
60.5 |
2 1/4 |
666.8 |
|
40" |
1320.8 |
158.8 |
263.7 |
1073.2 |
997.0 |
990.6 |
1016.0 |
1111.3 |
14.2 |
1212.9 |
32 |
60.5 |
2 1/4 |
739.4 |
|
42" |
1403.4 |
168.1 |
279.4 |
1127.3 |
1047.8 |
1041.4 |
1066.8 |
1168.4 |
14.2 |
1282.7 |
28 |
66.5 |
2 1/2 |
920.8 |
|
44" |
1454.2 |
173.0 |
289.1 |
1181.1 |
1098.6 |
1092.2 |
1117.6 |
1225.6 |
14.2 |
1333.5 |
32 |
66.5 |
2 1/2 |
979.8 |
|
46" |
1511.3 |
179.3 |
300.0 |
1234.9 |
1149.4 |
1143.0 |
1168.4 |
1276.4 |
14.2 |
1390.7 |
32 |
66.5 |
2 1/2 |
1093.2 |
|
48" |
1593.9 |
189.0 |
316.0 |
1289.1 |
1200.2 |
1193.8 |
1219.2 |
1333.5 |
14.2 |
1460.5 |
32 |
73.2 |
2 3/4 |
1295.0 |
|
50" |
1670.1 |
196.9 |
328.7 |
1343.2 |
1251.0 |
1244.6 |
1270.0 |
1384.3 |
14.2 |
1524.0 |
28 |
79.2 |
3 |
1510.5 |
|
52" |
1720.9 |
203.2 |
336.6 |
1394.0 |
1301.8 |
1295.4 |
1320.8 |
1435.1 |
14.2 |
1574.8 |
32 |
79.2 |
3 |
1614.8 |
|
54" |
1778.0 |
209.6 |
349.3 |
1447.8 |
1352.6 |
1346.2 |
1371.6 |
1492.3 |
14.2 |
1632.0 |
32 |
79.2 |
3 |
1778.1 |
|
56" |
1854.2 |
217.4 |
362.0 |
1501.6 |
1403.4 |
1397.0 |
1422.4 |
1543.1 |
15.7 |
1695.5 |
32 |
85.9 |
3 1/4 |
1941.4 |
|
58" |
1905.0 |
222.3 |
369.8 |
1552.4 |
1454.2 |
1477.8 |
1473.2 |
1600.2 |
15.7 |
1746.3 |
32 |
85.9 |
3 1/4 |
2104.7 |
|
60" |
1993.9 |
233.4 |
388.9 |
1609.9 |
1505.0 |
1498.6 |
1524.0 |
1657.4 |
17.5 |
1822.5 |
28 |
91.9 |
3 1/2 |
2268.0 |
Notes:
Raised Face height(f)will be furnished with 6.4mm and,which is included in Thickness(C)and Length Through Hub (Y).
