DIN Flanges Standard
China Flange Manufacturer - Kaysen Supplies Different standards flanges, like ASME B16.5 Flanges ,ASME B16.11 Flanges,ASME B16.36 Orifice Flanges, ASME B16.47 Flanges, MSS SP44 Flanges ,API605 Flanges, JIS/KS Flange, DIN Standard, EN 1092-1 Flanges, BS 4504 Flange, Gost Flanges, AS Flange,UNI Flanges ,ISO Flanges,etc.
Today I will introduce the details of the Din Flanges Standards:
| Description | Rated Pressure (in bar) (1 bar = 14.5 psi = 100 kPa) | ||||||||||||
| 1 | 2.5 | 6 | 10 | 16 | 25 | 40 | 64 | 100 | 160 | 250 | 320 | 400 | |
| DIN | |||||||||||||
| Blind Flange | 2527 | 2527 | 2527 | 2527 | 2527 | 2527 | 2527 | ||||||
| Flat flange for welding (slip on) |
2573 | 2576 | 2502 | 2503 | 2503 | ||||||||
| Welding neck flange | 2630 | 2630 | 2631 | 2632 | 2633 | 2634 | 2635 | 2636 | 2637 | 2638 | 2628 | 2629 | 2627 |
| Lapped (lapped joint) flange, Plain collar |
2641 | 2642 | |||||||||||
| Loose flange and ring for welding (slip-on flange and plain collar) |
2652 | 2653 | 2655 | 2656 | |||||||||
| Loose flange and ring with neck for welding |
2673 | ||||||||||||
| Oval plain threaded flange | 2588 | ||||||||||||
| Oval flange, with neck threaded |
2561 | 2561 | |||||||||||
| Threaded flange with neck | 2565 | 2566 | 2566 | 2567 | 2567 | 2568 | 2569 | ||||||
| Long neck welding flange | 28115 | 28115 | |||||||||||
| Hubbed slip-on Flange for welding |
86029 | 86030 | |||||||||||
